EQUIPMENT
Head Office Factory
Design Office
This is a specialized department at the Head Office Factory that uses CAD to carry out the overall design, drafting, and creation of processing data for broaches. A system is in place to respond quickly to customer requests.
Broach Factory
We manufacture a wide variety of broach tools used in automobile parts production and other applications. By making full use of general-purpose machines that require skilled craftsmanship and NC machines controlled by programming, we achieve the production of high-quality products.
List of Installed Equipment
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| General-purpose Surface Grinder |
PSG-104CA | Okamoto Machine Tool Works |
1000×400mm |
| General-purpose Surface Grinder |
SGW-64 | Nagase | 600×400mm |
| General-purpose Surface Grinder |
SGS-12 | Sanjo Machine Works | 1200×300mm |
| NC Surface Grinder | TS-126 | Amada | 1200×300mm |
| General-purpose Profile Grinder |
GS-BM3 | Kuroda | 500×120mm |
| General-purpose Profile Grinder |
GOP32×150 | TOYODA | Max. machining diameter Φ100 Max. length 1500mm |
| General-purpose Profile Grinder |
GP-30B・200H | Shigiya | Max. machining diameter Φ150 Max. length 2000mm |
| CNC Grinder | PSG-106CA3 | Okamoto Machine Tool Works |
Max. machining diameter Φ50 Max. length 1000mm |
| CNC Grinder | PSG-305DXNC | Okamoto Machine Tool Works |
Max. machining diameter Φ180 Max. length 2000mm |
| Automatic Relief Grinding Machine |
NBSG-NC10 | Nitto Precision Industry |
Max. machining diameter Φ70 Max. length 1200mm |
NC Surface Grinder
Surface Grinder
Surface Grinder
Column-type Grinder
CNC Grinder
Column-type CNC Surface Grinder
Fukaya Plant No.1
Design Office
The Design Office mainly engages in the design and production of rubber molding dies for automobiles, medical devices, and office automation equipment such as printers. It handles compression molds, transfer molds, and injection molds.
Mold Factory
In a factory with 24-hour temperature control, high-performance machining equipment is used to manufacture rubber molding dies, knockout jigs, and inspection jigs. We can accommodate customers’ desired shapes, materials, and sizes, as well as various surface treatments and polishing processes.
List of Installed Equipment
| Type | Model | Manufacturer | Specifications | Machining Center | V22 | Makino Milling Machine | Stroke 320×280×300mm |
|---|---|---|---|
| Machining Center | V33 | Makino Milling Machine | Stroke 600×400×350mm |
| Machining Center | V33i | Makino Milling Machine | Stroke 600×400×350mm |
| Machining Center | V55 | Makino Milling Machine | Stroke 900×550×450mm |
| Machining Center | V56 | Makino Milling Machine | Stroke 900×550×450mm |
| Machining Center | V56i | Makino Milling Machine | Stroke 900×550×450mm |
| Machining Center | V77 | Makino Milling Machine | Stroke 1200×700×650mm |
| CNC Jig Borer | YBM-950V | Yasda Precision Tools | Stroke 900×500×350mm |
| NC Milling Machine | BN85 | Makino Milling Machine | Stroke 850×500×400mm |
| NC Milling Machine | ANC85 | Makino Milling Machine | Stroke 850×500×400mm |
| NC EDM | EDNC65 | Makino Milling Machine | Stroke 650×450×350mm |
| NC EDM | EDNC85 | Makino Milling Machine | Stroke 800×500×350mm |
| Surface Grinder | PSG106CA | Okamoto Machine Tool Works |
Stroke 1016×600mm |
| Sandblasting Equipment | SGK-3ST | Fuji Manufacturing | Cabinet 805×1580×605mm |
Machining Center
Machining Center
Jig Borer
Fukaya Plant No.2
We manufacture ejector pins used in die-cast molding and other production processes to form holes and bosses in products. By leveraging our broach manufacturing expertise and experience, we provide high-precision and high-quality products.
List of Installed Equipment
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| Petermann Lathe (NC Lathe) |
M32 4M 5 Type | Citizen | Max machining diameter Φ32 Max length 500mm |
| Petermann Lathe (NC Lathe) |
M16 4M 5 Type | Citizen | Max machining diameter Φ16 Max length 500mm |
| Petermann Lathe (NC Lathe) |
BU38-SY | Tsugami | Max machining diameter Φ36 Max length 500mm |
| Gun Drill | MLG-500S | Miroku | Max machining diameter Φ10 Max length 485mm |
| NC Milling Machine | AN-SRW | Shizuoka | Max machining diameter Φ36 Max length 350mm |
| General-purpose Cylindrical Grinder |
PUG-45P | Maruei | Maruei | Max machining diameter Φ36 Max length 480mm |
| Mirror Shot Machine SMAP | SMAPⅡ Type | TOYO | Max machining diameter Φ36 Max length 550mm |
Petermann Lathe (NC Lathe)
Petermann Lathe (NC Lathe)
Gun Drill
Fukaya Plant No.3
This plant handles the final process of broach tools, known as the “life of the tool” - blade finishing. By carefully grinding the blade backs, we improve sharpness before delivering them to customers. We also perform regrinding of tools whose accuracy has declined.
List of Installed Equipment
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| NC Sharpener (Round) | NBG-NC15 | Nitto Precision Industry |
Max diameter Φ150 / Min diameter Φ10 Max length 1500mm |
| NC Sharpener (Flat) | NBG-NC200 | Nitto Precision Industry |
Max height 130mm / Max length 1200mm Max depth 250mm |
| NC Nicking Machine | MO537 | Noah Engineer | Max diameter Φ100 / Min diameter Φ10 Max length 1900mm |
| General-purpose Sharpener (Round) |
Unknown | NACHI | Max diameter Φ150 / Min diameter Φ5 Max length 2000mm |
| General-purpose Sharpener (Flat) |
Unknown | NACHI | Max height 130mm / Max length 1200mm Max depth 250mm |
| CNC Surface Grinder | PSG155DXNC | Okamoto Machine Tool Works |
Max length 1200mm Max depth 250mm |
NC Sharpener (Round)
CNC Surface Grinder
3D Measuring Machine
Obusuma Plant
This plant handles processes up to the heat treatment of broach tools. Using NC machines and general-purpose machines, we manufacture a wide variety of shapes from raw materials. We strive to improve accuracy so that subsequent processing can be carried out smoothly.
List of Installed Equipment
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| EG-type Milling Machine | RT-US5N-EG | Takeda | Max width 300mm / Max length 1300mm |
| Bed-type Milling Machine | MH-4P | OKK | Max width 125mm / Max length 900mm |
| NC Milling Machine | MH-3NCV | OKK | Max width 300mm / Max length 900mm |
| Machining Center | VM5-3 | OKK | Max width 220mm / Max length 800mm |
| NC Lathe | WT-300 | Nakamura-Tome | Max diameter Φ53 / Max length 1900mm |
| NC Lathe | WT-250Ⅱ | Nakamura-Tome | Max diameter Φ44 / Max length 1450mm |
| NC Milling Machine | YZ-500SG | Yamazaki Giken | Max width 250mm / Max length 1000mm |
| General-purpose Lathe | MARKⅡ | Yamazaki Mazak | Max diameter Φ140 / Max length 1900mm |
| General-purpose Lathe | MK860 | Yamazaki Mazak | Max diameter Φ65 / Max length 1000mm |
NC Lathe
NC Lathe
Machining Center
